Kyoritsu 3022A Insulation/Continuity Tester Memory function up to 99 data
RM1,950.00
Kyoritsu 3022A Insulation/Continuity Tester Memory function up to 99 data
Price RM1,950.00
Product SKU Kyoritsu 3022A
Brand Kyoritsu
Availability In Stock
Shipping Fee
Quantity
Description
Highlight

Kyoritsu 3022A Insulation/Continuity Tester Memory function up to 99 data

•3 functions in one unit, insulation test with 4 voltage ranges, continuity test, AC voltage measurement

•200mA measuring current on continuity testing

•Comparator function with PASS / FAIL and buzzer

•0Ω adjustment at continuity measuring range

•Memory function up to 99 data

•Backlight LCD provides easy reading in dark locations

•Safety lock system prevents an erroneous operation on 500 and 1000 Volt ranges

•Safety standard IEC 61010-01 CAT.III 600V

Kyoritsu 3022A Insulation/Continuity Tester Memory function up to 99 data

•3 functions in one unit, insulation test with 4 voltage ranges, continuity test, AC voltage measurement

•200mA measuring current on continuity testing

•Comparator function with PASS / FAIL and buzzer

•0Ω adjustment at continuity measuring range

•Memory function up to 99 data

•Backlight LCD provides easy reading in dark locations

•Safety lock system prevents an erroneous operation on 500 and 1000 Volt ranges

•Safety standard IEC 61010-01 CAT.III 600V





Insulation resistance

Test voltage

50V

100V

250V

500V

Measuring range
(Auto range)

4.000/40.00/200.0MΩ

4.000/40.00/400.0/2000MΩ

First Effective Measuring range

0.1~20MΩ

0.1~40MΩ

0.1~200MΩ

Mid-scale value

5MΩ

50MΩ

Accuracy

|±2%rdg±6dgt

Second effective measuring range lower

0~0.099MΩ

Second effective measuring range upper

20.01~
200.0MΩ

40.01~
2000MΩ

200.1~
2000MΩ

Accuracy

|±5%rdg±6dgt

Rated current

DC 1~1.2mA

Output short circuit current

1.5mA max

Ω/Continuity

Auto range

40.00/400.0Ω

Accuracy

|±2%rdg±8dgt

Output Voltage on open circuit

5V±20%

Output short circuit current

DC 220±20mA

Fuse

Quick acting ceramic fuse 0.5A/600V (Ø6.35×32mm)

AC Voltage

Range

AC 20~600V (50/60Hz)
DC -20~-600V/+20~+600V

Accuracy

|±3%rdg±6dgt

General

Applicable standards

IEC 61010-1 CAT.III 600V, IEC 61557-1,2,4, IEC 61326-1 (EMC), IEC 60529 (IP40)

Dimensions / Weight

105(L) × 158(W) × 70(D)mm / 600g approx.

Power source

R6P×6 or LR6×6

Accessories

7150A (Remote control switch set),
9121 (Shoulder strap), R6P (AA)×6, Instruction Manual

Optional

7115 (Extension Probe), 8016 (Hook type prod),
8923 (Fuse [0.5A/600V]), 9089 (Carrying Case)
