Name: Fluke 83V (83-5) Digital Multimeter
Brand: Fluke
SKU: fluke 83V (83-5)
Price: 2880.00 MYR
Availability: InStock

RM2,880.00

Fluke 83V (83-5) Digital Multimeter

Price	RM2,880.00
Product SKU	fluke 83V (83-5)
Brand	Fluke
Availability	In Stock
Shipping Fee

Quantity

Product
Description
Reviews (0)

Description

Fluke 83V Digital Multimeter

FLUKE 83-5

From the control room to the plant floor, the Fluke 80 Series family of digital multimeters has earned its reputation as the digital multimeter industrial technicians trust. When productivity is on the line, the Fluke 80 Series delivers the accuracy and advanced troubleshooting capabilities you need to solve problems fast.

Use its low pass filter function to measure voltage and frequency accurately on electrically “noisy equipment like adjustable speed motor drives. Use the peak capture function to detect intermittent problems and transients as fast as 250 micro seconds (µs).

And work with confidence. The Input Alert function gives you an audible warning against wrong use of input jacks. Fluke 80 Series multimeters are independently tested for use in CAT IV 600V/CAT III 1000V environments. They can withstand impulses in excess of 8,000 V and reduce risks related to surges and spikes.

At Fluke, our ideas come straight from the job site. We work with users like you to create test tools that do the job you want for as long as you need it—and give you full value. We design and build Fluke 80 Series multimeters in the U.S.A. The 80 series is backed by our limited lifetime warranty. And we back them with our limited lifetime warranty so you can work smarter, faster and safer.

Features and benefits of the Fluke 83V series

Unique function for accurate voltage and frequency measurements on adjustable speed motor drives and other electrically noisy equipment (87V)
Built-in thermometer conveniently allows you to take temperature readings without having to carry a separate instrument (87V)
Optional magnetic hanger for easy set-up and viewing while freeing your hands for other tasks
Large digit display with bright, two-level backlight makes the 80- Series V significantly easier to read than older models

Specifications

Voltage DC

Maximum Voltage:	1000V
Accuracy:	Fluke 83 V: ±(0.1%+1)
	Fluke 87 V: ±(0.05%+1)
Maximum Resolution:	Fluke 83 V: 100 µV
	Fluke 87 V: 10 µV

Voltage AC

Maximum Voltage:	1000V
Accuracy:	Fluke 83 V: ±(0.5%+2)
	Fluke 87 V: ±(0.7%+2) True RMS
AC Bandwidth	Fluke 83 V: 5kHz
	Fluke 87 V: 20kHz*
	*with low pass filter; 3db @ 1kHz
Maximum Resolution:	0.1 mV

Current DC

Maximum Amps:	10A (20 A for 30 seconds maximum)
Amps Accuracy:	Fluke 83 V: ±(0.4%+2)
	Fluke 87 V: ±(0.2%+2)
Maximum Resolution:	Fluke 83 V: 0.01 mA
	Fluke 87 V: 0.01 µA

Current AC

Maximum Amps:	10A (20 A for 30 seconds maximum)
Amps Accuracy:	Fluke 83 V: ±(1.2%+2)
	Fluke 87 V: ±(1.0%+2) True RMS
Maximum Resolution:	0.1 µA

Resistance

Maximum Resistance:	50 MΩ
Accuracy:	Fluke 83 V: ±(0.4%+1)
	Fluke 87 V: ±(0.2%+1)
Maximum Resolution:	0.1Ω

Capacitance

Maximum Capacitance	9,999 µF
Accuracy	±(1%+2)
Maximum Resolution	0.01 nF

Frequency

Maximum Frequency	200 kHz
Accuracy	±(0.005%+1)
Maximum Resolution	0.01 Hz

Duty Cycle

Maximum Duty Cycle	99.9%
Accuracy	±(0.2% per khz +0.1%)
Maximum Resolution	0.1%

Temperature Measurement

Fluke 87 V, 87 V/E:	-200.0°C - 1090°C
	-328.0°F - 1994.0°F
	excluding probe

80 BK Temperature Probe

	-40.0°C - 260°C
	-40.0°F - 500°F, 2.2°C or 2% whichever is greater

Conductance

Maximum Conductance	60.00 nS
Accuracy	±(1.0%+10)
Maximum Resolution	0.01 nS

Diode

Range:	3 V
Resolution:	1 mV
Accuracy:	± (2 % + 1)

Duty Cycle Range

Accuracy:

Within ± (0.2% per kHz + 0.1 %)

Environmental Specifications

Operating Temperature

-20°C to +55°C

Storage Temperature

-40°C to +60°C

Humidity (Without Condensation)

	0% - 90% (0°C - 35°C)
	0% - 70% (35°C - 55°C)

Operating Altitude

2000 m

Safety Specifications

Overvoltage category

EN 61010-1 to 1000 V CAT III, 600V CAT IV

Agency Approvals

UL, CSA, TÜV, VDE listed

Mechanical & General Specifications

Size

201 x 98 x 52 mm (with holster)

Weight

355 g

Weigh With Holster and Flex-Stand

624 g

Display

Digital:	6000 counts updates 4/sec.
	(Model 87 also has 19,999 counts in high-resolution mode.)
Analog:	32 segments, updates 40/sec.
Frequency:	19,999 counts, updates 3/sec at > 10 Hz.
